INDOOR LED DISPLAY RENTAL TYPE

BLACK SMD KINGLIGHT

NOVASTAR A8S-N CARD

Cabinet size (W×H×D) mm 500×500

Pixel size 1.95 mm

Type LED Black SMD 1515

Brightness 800 -1000cd/m²

Contrast ratio 5000:1

Horizontal viewing angle 160°

Vertical viewing angle 140°

Module resolution 128×128 pixels

Color temperature 2000 to 9500K adjustable

Module size (W×H) mm 250×250

Pixel density 262144 pixels/m²

Pixel per panel resolution 256×256 pixels

Processing depth 16bit

Maintenance method Rear service

Protection level IP54

Panel corner protection Yes

Cabinet material Die-cast aluminum

Curved (convex/concave) -15/+15 degrees

Control system Novastar A8s – N

Average power consumption 224W/ m²

Maximum power consumption 464W/ m²

Operating temperature
humidity range
-20℃~+50℃/10~90%RH
